5G Power amplifier

Demystifying 5G – 5G power amplifier characterization

In this video we explore how to set up Rohde & Schwarz signal generators and spectrum analyzers to characterize a 5G power amplifier using 5G waveform candidates, such as FBMC, UFMC or GFDM.

The demystifying 5G video series discusses main topics related to 5G including requirements, timeline, potential frequency and waveform candidates.
