Key facts
Starting at USD 8,440
The R&S®MXO 4 series is the first of a new generation of oscilloscopes that excels in both performance and value. The instruments deliver a once-in-a-decade engineering breakthrough for accelerated insight.
They have the world’s fastest real-time update rate of 4.5 million waveforms/s, meaning engineers can see more infrequent events than with any other instrument. The 12-bit ADC in the R&S®MXO 4 series has 16 times the resolution of traditional 8-bit oscilloscopes at all sample rates for more precise measurements without any compromises. A standard 400 Mpoint acquisition memory on all four channels and an optional 800 Mpoint interleaved memory provide the instrument with up to 100 times the standard memory of comparable instruments.
A class above similar oscilloscopes, R&S®MXO 4 series oscilloscopes sport an impressive 13.3" Full HD capacitive touchscreen and an intuitive user interface with a learning curve of less than 15 minutes.
... with unparalleled update rate
Typical update rate (left) vs. 4.5 million waveforms/s (right)
… with lowest measurement noise and highest vertical resolution
Typical vertical resolution (left) vs. 18 bit resolution HD Mode (right)
… with the deepest standard memory
Slow (left) vs. fast sample rate (right) with a long capture window
… with high-precision digital trigger
Flexible triggering with digital trigger and HD mode
… with advanced usability designed for touch
15-Minute learning curve, superior touch, intuitive navigation
... with dedicated RF controls
Superior RF measurement capability
| Vertical system | ||
| Analog channels | 4 | |
| Digital channels (opt.) | 16 | |
| Analog bandwidth (–3 dB) | R&S®MXO 4 with (R&S®MXO 4 -B24x options) | 200 MHz, 350 MHz, 500 MHz, 1 GHz, 1.5 GHz |
| Rise time | R&S®MXO 4 (with R&S®MXO 4 -B24x options) | 1.75 ns, 1 ns, 700 ps, 350 ps, 234 ps |
| Input impedance | 50 Ω ± 1.5 %, 1 MΩ ± 1 % || 12 pF (meas.) |
|
| Input sensitivity | at 50 Ω | 0.5 mV/div to 1 V/div, entire analog bandwidth supported for all input sensitivities |
| at 1 MΩ | 0.5 mV/div to 10 V/div, entire analog bandwidth supported for all input sensitivities |
|
| Vertical resolution | up to 18 bit with HD mode (high definition) | |
| DC gain accuracy | offset and position set to 0 V, after self-alignment | |
| input sensitivity > 5 mV/div | ±1 % full scale | |
| input sensitivity ≤ 5 mV/div to ≥ 1 mV/div | ±1.5 % full scale | |
| input sensitivity < 1 mV/div | ±2.5 % full scale | |
| Acquisition system | ||
| Sampling rate | analog channels (real time) | max. 5 Gsample/s on 2 channels, max. 2.5 Gsample/s on 4 channels |
| analog channels (interpolated) | max. 5 Tsample/s | |
| digital channels | max. 5 Gsample/s on each channel | |
| Acquisition memory | standard | 400 Mpoints with 4 active channel (single), 400 Mpoints with 2 active channel (run) |
| R&S®MXO4-B108 option | 800 Mpoints with 2 active channel (single), 800 Mpoints with 1 active channel (run) |
|
| Max. acquisition rate | > 4 500 000 waveforms/s | |
| Acquisition modes | sample, peak detect, average, envelope | |
| Interpolation modes | linear, sin(x)/x, sample & hold | |
| Horizontal system | ||
| Timebase range | Selectable between 200 ps/div and 10 000 s/div |
|
| Timebase accuracy | after delivery/calibration, at +23 °C | ±0.2 ppm |
| During calibration interval | ±1 ppm | |
| Channel-to-channel skew | between analog channels | < 100 ps (meas.) |
| between digital channels | < 500 ps (meas.) | |
| Trigger system | ||
| Standard trigger types | Edge, glitch, width, runt, window, timeout, interval, slew rate, setup&hold, pattern, state | |
| Advanced trigger modes | A/B/R, serial bus, trigger in and out | |
| Trigger sensitivity | 0.0001 div, from DC to instrument bandwidth for all vertical scales |
|
| Analysis and measurement | ||
| Automatic measurements | 39 | |
| Cursor measurements | 4 | |
| Waveform mathematics | Up to 5 equations math on math (add, subtract, multiply, divide, absolute value, square, square root, integrate, differentiate, log10, loge, log2, reciprocal, invert, low pass, high pass, rescale (a*x+b)) |
|
| Logic analyzer (MSO) functionality | ||
| Digital input channels | 16 | |
| MSO Bandwidth | 400 MHz | |
| MSO sampling rate | 5 Gsamples/s per channel | |
| General data | ||
| Dimensions | W × H × D | 414 mm × 279 mm × 162 mm (16.3 in × 10.99 in × 6.38 in) |
| Weight | without options, nominal | 6.0 kg (13.23 lb) |
| Interfaces | 1 x USB 3.0 super speed port 2 x USB 2.0 high speed port 2 x USB 3.1 gen1 ports 1 x USB 3.1 gen1, type B plug 1 Gbps LAN HDMI for external monitor External trigger, trigger output Ref In, ref out VESA mount |
|
| Display | type | 13.3" LC TFT color display with capacitive touchscreen |
Order number 1335.4130.02
Mixed signal option for R&S®MXO 4 series with 16 digital channels
Order number 1335.4147.02
Arbitrary waveform generator, 100 MHz, 2 analog channels
Order number 1335.5772.02
Memory upgrade to 800 Mpoints on 2 channels
Order number 1335.4276.02
Upgrade of R&S®MXO 4 series oscilloscopes to 350 MHz bandwidth
Order number 1335.4299.02
Upgrade of R&S®MXO 4 series oscilloscopes to 500 MHz bandwidth
Order number 1335.4318.02
Upgrade of R&S®MXO 4 series oscilloscopes to 1 GHz bandwidth
Order number 1335.4330.02
Upgrade of R&S®MXO 4 series oscilloscopes to 1.5 GHz bandwidth
Order number 1335.5195.02
Low speed serial triggering and decode (I2C/SPI/UART/RS-232/RS-422/RS-485)
Order number 1335.5214.02
SPMI serial decode
Order number 1335.5943.02
Automotive ethernet decode package: 10BASE-T1S
Order number 1335.5566.02
Power analysis
Order number 1335.5572.02
Frequency response analysis (require MXO4-B6 as source)
Order number 1335.4360.02
Front cover: protects the front of the R&S®MXO 4 oscilloscope
Order number 1335.5589.02
Soft case stores the R&S®MXO 4 oscilloscope and accessories
Order number 1335.5595.02
Transit case protects the R&S®MXO 4 oscilloscope and accessories during transport
Order number 1335.5108.02
Rackmount kit for R&S®MXO 4 oscilloscopes with 6 HU
Order number 1333.2401.02
Passive probe, 500 MHz, 10:1
Order number 1333.1370.02
Passive probe, 38 MHz, 1:1
Order number 1409.7550.00
Passive probe, 500 MHz, 10:1
Order number 1803.0005.02
Passive probe, 700 MHz, 10:1
Order number 1418.7007.02
Active single-ended probe, 1 GHz, Rohde & Schwarz probe interface
Order number 1410.4080.02
Active single-ended probe, 1 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order number 1410.3502.02
Active single-ended probe, 1.5 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order number 1410.4715.02
Active differential probe, 1 GHz, Rohde & Schwarz probe interface
Order number 1410.4409.02
Active differential probe, 1.5 GHz, Rohde & Schwarz probe interface
Order number 1800.5006.02
Power rail probe, 2 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
2.0 GHz, 1:1, 50 kΩ, R&S probe interface
Order number 1333.0873.02
250 MHz passive high voltage probe
Order number 1409.7737.02
400 MHz passive high voltage probe
Order number 1409.7720.02
400 MHz passive high voltage probe
Order number 1800.2307.02
200 MHz High voltage differential probe
Order number 1800.2107.02
100 MHz High voltage differential probe
Order number 1800.2207.02
200 MHz High voltage differential probe
Order number 1800.2007.02
100 MHz High voltage differential probe
Order number 1333.0850.02
AC/DC 20 kHz current probe
Order number 1409.8204.02
2 MHZ current probe
Order number 1409.7750K02
10 MHZ current probe
Order number 1409.8227.02
50 MHZ Current probe
Order number 1409.8210.02
10 MHZ Current probe
Order number 1409.7766K02
100 MHZ current probe
Order number 1409.8233.02
100 MHZ current probe
Order number 1409.7772K02
120 MHz current probe
Order number 1801.4932.02
120 MHz current probe
Order number 1333.0844.02
100 kHz current probe
Order number 1800.4700.02
Modular probe amplifier module, 1.5 GHz
Order number 1333.0721.02
400 MHz logic probe
Order number 1147.2736.02
E and H near-field probe set
Order number 1409.7789.02
Power supply for probes
Power supply for R&S®RT-ZC10/20/30 probes, +/-12V DC, +/-2.5A
Order number 1410.4744.02
External attenuator
10:1, 2.0 GHz, 1.3 pF, 60 V DC, 42 V AC (peak) for R&S®RT-ZD20/30 probes. Included in R&S®RT-ZD10.
Order number 1326.3641.02
3D probe positioner
3D positionier with central tensioning knob for easy clamping and positioning of probes (span width: 200 mm, clamping range: 15 mm)
Order number 1800.0004.02
Power deskew fixture
Deskew fixture for voltage and current probes for power measurements; includes USB 2.0 cable for power supply
